Tire specification	Ply	Load Index	Load(kg		Air Pressure(kpa)		Speed Level	Measured rims	Allowable rims	New tire tread depth(mm)	行驶面宽度(mm)	New tire designed size(mm
			Single Tire	Double Tire	Single Tire	Double Tire						Section width	Outer diameter
10.00R20	18	149/146	3250	3000	930	930	K	7.5	8.0,7.50V	18	215	278	1054
11.00R20	18	152/149	3550	3250	930	930	K	8	8.5,8.00V	20	223	293	1085
12.00R20	18	154/151	3750	3450	830	830	K	8.5	9.0,8.50V	20	238	315	1125
7.00R16LT(TL-TB)	14	118/114	1320	1180	770	770	J	5.50F	6.00G	13.5	152	214	800
295/80R22.5、w)	18	152/149	3550	3250	900	900	K	9	8.25	22	246	298	1044
315/80R22.5、W、	20	156/150	4000	3350	850	850	K	9	9.75	22	255	312	1076

Features and Benefits of Huaguan Tire 511 Tires

Suitable for low-speed driving in mines, rugged roads, etc.

Deep block design, with good wear resistance, cut resistance and tear resistance;

New tire bead structure design, excellent load-bearing capacity.

Safety Warning Tips of Huaguan Tire 511 Tires

Excessive or low tire pressure may cause premature tire damage. Follow the tire manual or vehicle bulletin.

Only specially trained personnel can assemble tires, otherwise it may cause tire/rim assembly to be improper and burst.
